--- title: SMART BILGE + Autoclean installation guide description: Detailed guidance on installing an Auto-Clean system to your SmartBilge+ oil content meter. --- [Skip to content](https://hub.rivertrace.com/knowledge/smartbilge-autoclean-installation-guide#main-content) English Show submenu for translations [Submit a request](https://hub.rivertrace.com/knowledge/kb-tickets/new) [![Rivertrace-Logo-Blue-on-White](https://hub.rivertrace.com/hs-fs/hubfs/Rivertrace%20Logos/Rivertrace-Logo-Blue-on-White.jpg?width=412&height=150&name=Rivertrace-Logo-Blue-on-White.jpg)](https://www.rivertrace.com) Open main navigation Close main navigation - English Show submenu for translations - [Submit a request](https://hub.rivertrace.com/knowledge/kb-tickets/new) - [Cant find what you need? Contact our remote support team.](mailto:remotesupport@rivertrace.com) [Cant find what you need? Contact our remote support team.](mailto:remotesupport@rivertrace.com) How can we help you? - There are no suggestions because the search field is empty. 1. [Knowledge Base](https://hub.rivertrace.com/knowledge) 2. [Smart Bilge+ Plus](https://hub.rivertrace.com/knowledge/smart-bilge-plus) # SMART BILGE + Autoclean installation guide ## Detailed guidance on installing an Auto-Clean system to your SMART BILGE + oil content meter. ### **Introduction** The autoclean option for the SMART BILGE+ is a pneumatic autoclean plunger with wiper blade, designed to ensure that the measuring cell glass tube is kept free from fouling. This option replaces the manual clean system on the monitor and its automated process removes the need for an operator to clean the cell. For this system to function the autoclean will require a constant 6 bar air supply. It is assumed that the installer will ensure that he will isolate power when carrying out the installation and will not work on live equipment. ### **Installation kit** The installation kit for the SMART BILGE + autoclean comes in three configurations: SMART BILGE + 24VAC Autoclean hardware kit – Rivertrace Part No: 110226  SMART BILGE+ 115VAC Autoclean hardware kit – Rivertrace Part No: 110225  SMART BILGE+ 230VAC Autoclean hardware kit – Rivertrace Part No: 110224  Each assembly consists of a solenoid assembly of the appropriate voltage and an actuator assembly. | 110222 | AUTOCLEAN 24VAC SOLENOID ASSEMBLY | ![Solenoid assembly](https://hub.rivertrace.com/hs-fs/hubfs/image-png-Aug-05-2024-10-03-42-2879-AM.png?width=670&height=676&name=image-png-Aug-05-2024-10-03-42-2879-AM.png) | | --- | --- | --- | | 110221 |  AUTOCLEAN 115VAC SOLENOID ASSEMBLY | | | 110220 | AUTOCLEAN 230VAC SOLENOID ASSEMBLY | | | 110223 |  AUTOCLEAN ACTUATOR ASSEMBLY |                     ![Autoclean actuator](https://hub.rivertrace.com/hs-fs/hubfs/image-png-Aug-05-2024-10-05-12-7398-AM.png?width=92&height=250&name=image-png-Aug-05-2024-10-05-12-7398-AM.png) |   ### **Instructions** #### **Preparing the SMART BILGE+** Cut all water from the monitor to ensure the measuring cell is empty. Remove the manual clean assembly from SMART BILGE+ from the cell by unscrewing it using the knurled section. This can be stored as a spare. #### **Installing the solenoid** To secure the solenoid to the SMART BILGE+, the two M4 screws and washers must be removed from the bracket above the PCB module. The two holes on the solenoid bracket can then be lined up with the now empty holes and the fasteners reattached.   ![Installing the solenoid](https://hub.rivertrace.com/hs-fs/hubfs/image-png-Aug-05-2024-10-41-08-7873-AM.png?width=514&height=409&name=image-png-Aug-05-2024-10-41-08-7873-AM.png)   Remove front cover from microcontroller module using a small Philips screwdriver then remove the clear protective cover within the enclosure using a small flat bladed screwdriver. The cable from the solenoid must be inserted through the gland on the underside into the enclosure.   ![Solenoid cabling](https://hub.rivertrace.com/hs-fs/hubfs/image-png-Aug-05-2024-11-22-46-4635-AM.png?width=589&height=226&name=image-png-Aug-05-2024-11-22-46-4635-AM.png)   Internally the solenoid cable must be connected to the Auto-Clean header CON2 according to the image below.   ![Solenoid PCB connection](https://hub.rivertrace.com/hs-fs/hubfs/image-png-Aug-05-2024-11-25-27-0138-AM.png?width=481&height=455&name=image-png-Aug-05-2024-11-25-27-0138-AM.png) #### **Installing the actuator** locate the round wiper blade on the actuator into the top of the Smart-Cell and press down until the threaded part engages. Continue to screw the actuator into the cell until tight ad the pneumatic fitting is pointing towards the solenoid. Use the supplied pneumatic hosing to attach the two assemblies together, this may have to be cut down. Attach the 4 bar air supply to the solenoid valve via the spare elbowed pneumatic fitting.     ![Actuator installation](https://hub.rivertrace.com/hs-fs/hubfs/image-png-Aug-05-2024-12-14-06-5422-PM.png?width=510&height=289&name=image-png-Aug-05-2024-12-14-06-5422-PM.png)   **Enabling the Autoclean** After installation of the auto clean the power needs to be restored to the monitor. The autoclean will now need to be enabled using your unique SMART BILGE + activation PIN. Please contact sales@rivertrace.com to obtain the PIN. This will be specific to your PCB serial number so please ensure that this is included with your enquiry.  **Setting up the Autoclean** With the autoclean enabled select "AUTOCLEAN"  from the SMART BILGE+ main menu. You can adjust the number of operations and time intervals between cleans within the sub menus. ### **Maintenance** It is recommended that the wiper on the autoclean is replaced every 6 months to maintain performance and to prevent damage to the cell. this can be purchased as a spare quoting part number 109039. - [Smart ODME](https://hub.rivertrace.com/knowledge/smart-odme) - [SmartBilge](https://hub.rivertrace.com/knowledge/smartbilge) - [Smart Bilge+ Plus](https://hub.rivertrace.com/knowledge/smart-bilge-plus) - [Smart PFM](https://hub.rivertrace.com/knowledge/smart-pfm) - [OCD CW](https://hub.rivertrace.com/knowledge/ocd-cw) - [Smart ESM](https://hub.rivertrace.com/knowledge/smart-esm) - [OCD Xtra](https://hub.rivertrace.com/knowledge/ocd-xtra) - [Smart 50M](https://hub.rivertrace.com/knowledge/smart-50m) - [Smart Turbidity](https://hub.rivertrace.com/knowledge/smart-turbidity) - [Sample conditions and general techniques](https://hub.rivertrace.com/knowledge/sample-conditions-and-general-techniques) - [General FAQs](https://hub.rivertrace.com/knowledge/general-faqs) - [Key MEPC Regulations and Rivertrace Solutions](https://hub.rivertrace.com/knowledge/key-mepc-regulations-and-rivertrace-solutions) - [OCD CM](https://hub.rivertrace.com/knowledge/ocd-cm) [![Rivertrace-Logo-Black](https://hub.rivertrace.com/hs-fs/hubfs/Rivertrace%20Logos/Rivertrace-Logo-Black.jpg?width=271&height=99&name=Rivertrace-Logo-Black.jpg "Rivertrace-Logo-Black")](https://www.rivertrace.com) Rivertrace Product, Regulation and Technical Support Knowledge Base Copyright © 2025, Rivertrace Limited
